Covoc 8770 Curtain Track is designed for use in hospitals, nursing homes, doctors' offices, laboratories and other types of facilities that use hospital-style privacy curtains. It can also be used in residential and commercial applications.
8770 Curtain Track is extruded 6063 T5 aluminum and measures 1-1/8" wide x 3/4" high. The track can be trimmed on-site with a hacksaw or electric chop saw. It's available in three finishes: Anodized Silver, Jet Black, and Pure White.
All components to install and operate 8770 Curtain Track are included. Covoc 8780 two-wheel carriers with hooks are designed to roll freely inside the track channel. Two end stops are supplied for each curtain track: one 8785 End Stop and one 8790 End Stop with Pullout. 8790 includes a dropout piece allowing you to easily exchange carriers without removing the track from the ceiling. Covoc 8795 Splices are provided to ensure track is properly aligned.
If you have ceiling obstructions like light fixtures, vents or sloped ceilings, you can install our cubicle track below the ceiling at a fixed level height using our 3/4" square suspension tubing and component parts. See 'Add Suspension Components' below for more information.
Each curtain track order includes:
- 3 roller carriers with hooks per foot of track
- 1 end stop per track
- 1 end stop with pullout per track
- All required splices
Shipping Information
Straight curtain track ships in equal-length sections cut to a maximum length of 48" inches per section. The exact length of each section depends on the total length of your track. We include all necessary splices at no additional charge.
If you need your track to ship in a single piece, please note the following: Uncut track orders up to 20 feet in length can be picked up at no additional charge via Will Call at our Fullerton, CA warehouse. Alternatively, we can provide standard and expedited shipping for straight tracks from 6 feet to 8 feet in length, subject to additional shipping charges. For tracks exceeding 8 feet in length to be shipped in a single piece, we can, in most cases, arrange motor freight shipping which will incur further additional shipping cost. Please contact us with any questions or to get started.
Optional Add-Ons:
Upgrade to Stainless Steel Hooks
Optional upgrade to stainless steel hooks on the roller carriers. Recommended if using the track in a wet environment such as a shower, locker room or pool area.
Add Beaded Chain Drops
Beaded chain drops can be used instead of nylon mesh when fire sprinklers are present.
Add Stainless Steel Beaded Chain Drops
Recommended if using the track in a wet environment such as a shower, locker room or pool area.
Add PVC Drops
PVC drops can be used instead of nylon mesh when fire sprinklers are present.
Add Suspension Components
Suspension posts are supplied to support the track every 36" to 48". One ceiling bracket and one track bracket are supplied for each suspension post. Two wall brackets are supplied for each track. Contact us for assistance if you need different size posts than offered or if you have a sloped ceiling.
Add Swivel Clip Installation Bracket
Swivel clip installation brackets can be used when you do not want to screw the track directly to the metal runner of the T-bar ceiling. The snap-on clip mounts to the metal runner of a standard T-bar ceiling and the track hangs below. Does NOT fit narrow-style T-bar or tegular T-bar where the ceiling tile extends below the metal runners.
Click here to view additional curtain track accessories.
How to Measure and Install 8770 Curtain Track
For measuring and installation instructions, watch our helpful videos below.
-
Love these for curtains!
We have been using the aluminum aluminum ceiling tracks to hang curtains for many years. They virtually disappear, and you have curtains that run from ceiling to floor. Very modern, clear, easy, and they look great! We just moved to a new home, and one of the first things I did was order more track for new curtains.
-
Arrived Bent and original rod lost in shipping
Box and rod had significant damage but due to time constraints I did not notify the company and with a little bending and cutting to size I had what I needed in length to finish the job. Covoc reply: Hi Scott, thank you for comments. We apologize for the inconvenience.
-
Perfect!
Easy to install, good quality. No complaints.
-
Great product, the track
Great product, would have like the option of a shinier crom, and more narrow design. Due to used as a home bathroom decor, and not medical need. Should advertise in regular bathroom decor. Think lots of people would love the idea of the rack on ceiling design.
-
Beautiful modern way to hang curtains
We use these tracks instead of curtain rods. We attach them to the ceiling about 2-3 inches away from the wall in front of the window, hang the curtain, and the tracks become nearly invisible - lovely to see curtain instead of rod. The rollers make opening and closing the curtains very easy. We love a cleam modern aesthetic, and these are perfect.
-
Went up pretty easily
I was surprised there was predrilled holes but other than that it went up (with the help of a friend) pretty easily. If 2 64+ women can put it up, just about anybody can. Only 4 stars as the end caps were a mystery for a while and the shipping is plenty (even though the company can do anything about that). Came in good shape and timely.
-
End caps were a puzzle
The track, and hangers were of excellent quality. The end caps were a puzzle and didn't seem to quite fit. Never was sure about how they attached
-
Exactly what I was expeccting!
excellent product. Too bad the shipping was so costly. (Almost didn't order because of the shipping cost!)
-
Sliding curtain track for ceiling.
The track and sliders are top notch. They work very well and were easy to install. The end cap with the removable block that allows you to add or subtract hangers was a different story. After mounting the track and the block I discovered that the block had bee painted into place. I could not remove it without taking the whole track down and prying so hard on the block that it bent it before it came loose. I would still recommend these items. Covoc: Thank you for your feedback. In response to your comment we are working to ensure our painted end caps with pullout will release properly.
Shipping
All items ship via UPS Ground unless you choose expedited shipping (UPS 2nd Day Air or UPS Next Day Air) or motor freight shipping at time of order.
Note: Shipping selection at checkout applies to how quickly your order is delivered once it has shipped from our warehouse. For example, if the product in your order ships within 5 business days and you select UPS 2nd Day Air shipping service at checkout, your order will leave our warehouse by the fifth business day after the date of your order, and will be delivered by the carrier within 2 business days. For UPS Ground shipping, delivery timeline may vary based on geographic proximity.
Curtain Track Shipping
Straight 8770 Curtain Track ships in equal-length sections cut to a maximum length of 48" inches per section, depending on the total length of your track. We include all necessary splices at no additional charge.
8770 Curtain Tracks with corner bends are cut for shipping as follows: Corner bends ship as 2 ft. x 2 ft. sections. Straight track sections ship in sections of equal length, cut to a maximum length of 48" inches per section, depending on the total length of your track. We include all necessary splices at no additional charge.
If you need your 8770 Curtain Track to ship in a single piece, please note the following: Uncut track up to 20 feet in length can be picked up at no additional charge via Will Call at our Fullerton, CA warehouse. Alternatively, we can provide standard and expedited shipping for straight tracks from 6 feet to 8 feet in length, subject to additional shipping charges. For tracks exceeding 8 feet in length to be shipped in a single piece, we can, in most cases, arrange motor freight shipping which will incur further additional shipping cost. Please contact us with any questions or to get started.
Flexible I-Beam Track orders ship in 90" (7.5 ft.) sections.
Returns
Privacy curtains are made to order and are not returnable.
Curtain tracks are returnable for up to 30 days after the date of delivery, and are subject to a re-stocking charge of 25%. Items must be in “as new” condition and the customer is responsible for return shipping charges. Please contact us for a Return Authorization number prior to shipping any returns.
Window shades, mini blinds and vertical blinds are made to order and are not returnable.
Please contact us immediately with any claims for shortages, damaged goods or manufacturing defects. We will make every effort to remedy the situation so you will be 100% satisfied with your product.
